Industrial Energy Storage
Commercial & Industrial Energy Storage Cabinet
Air-cooled 96 and 128 kWh LiFePO4 cabinets with IP54 protection, 90% depth of discharge, Class II surge protection, and layered fire safety.
- 96 and 128 kWh system configurations
- 62 / 64 kW rated power with ≥92% system efficiency
- IP54 dust and water protection
- Class II AC / DC surge protection
Core Features
Applications
Factories and machine tools
Commercial buildings and server rooms
Industrial solar self-consumption
Key Specifications
← Swipe to compare all models →
| Model | GS125-96AS | GS125-128AS |
|---|---|---|
| System Capacity | 96kWh | 128kWh |
| Rated Power | 62kW | 64kW |
| System Efficiency | ≥92% | |
| Cycle Life | ≥6,000 cycles | |
| Response Time | ≤1s | |
| Cell Specification | LiFePO4 3.2V / 314Ah | |
| Assembly Structure | 16S 6P | 16S 8P |
| Depth of Discharge | 90% | |
| DC Voltage Range | 332.8–467.2Vdc | |
| Max. Charge / Discharge Current | 200A | |
| Ingress Protection Rating | IP54 | |
| Lightning Protection | Class II SPD surge protection | |
| Thermal Management / Cooling Mode | Air cooling | |
| Fire Protection | Thermal aerosol + fire-water pipe | |
| Max. Operating Temperature - Charging | 0–55°C | |
| Max. Operating Temperature - Discharging | -20–55°C | |
| Communication | CAN / RS485 | |
| Air Conditioning System | Constant temperature model UNKSD0001.5CA | |
| Master-Slave BMS System | Jiabaida | |
| Grid-Tied / Off-Grid Switching Time | ≤20ms | |
| Dimensions | 2300×1050×740mm | 1800×1250×1050mm |
| Weight | 800kg | 1050kg |
